OFF ROAD USE
EVERY Pitster we sell is The Latest Version and
Excited about getting your bike, and setting it up? Pit Bike Shipping Info Pit Bike Set Up Info
Basics
Manufacturer
Pitster Pro
Model
MXR 140
MSRP
$1999.99 Available Colors
Gray
Engine
Displacement 140cc
Engine Type
Air cooled
Bore/Stroke
56mm x 57mm
Final Drive
420/ 16T X 39T
Fuel Delivery
22mm Carb
Fuel
Unleaded Pump Gas (Run Premium When Available)
Recommended Engine Oil
10W-40 Petroleum Based (Nonsynthetic)
Ignition
Kick Start
Yes
Electric Start
Yes
CDI
Yes
Auxiliary Output
Yes
Transmission
Transmission
Close ratio 4-speed semi-automatic transmission
Shift-Pattern
4-Up Clutch
Semi-automatic
Chassis
Front Suspension
GPX hydraulic telescopic oil fork
Rear Suspension Chromoly, single shock w/ adjustable preload
Travel
5" Front / 5" Rear Swing Arm
MX style
Frame
Chromoly with cradle
Subframe
Chromoly, removeable
Wheels
Front Wheel
2.5 x 17"
Front Tire
60/100-17
Front Brake
190mm W-style rotor w/ floating caliper
Rear Wheel
3.0 x 14"
Rear Tire
80/100 x 14
Rear Brake
190mm W-style rotor w/ floating caliper
Dimensions
Wheelbase
44.5 Inches
Seat Height
34.5 Inches
Curb Weight
148.5 lbs.
Fuel Capacity
1 Gallon
Ground Clearance
8.5 Inches
Overall Length
61 Inches
Overall Width
27.5 Inches
IMPORTANT ENGINE STARTING INFORMATION
You may want to consider setting up the bike on a stand for a solid starting location at first until your confident
Turn on Both Fuel and Choke
DO NOT open the throttle (do NOT turn the throttle)
Move the starter down until it gets stiffer, your looking for top dead center
Let the starter come back up and give a full strong swift kick ALL the way thru
REPEAT (If necessary)
DO NOT KICK RAPIDLY
When warm just do not use the choke
Flooded Engine:
IF your flooded , pull the plug, kick it over about 10 times WITH THE PLUG OUT
Put in a NEW PLUG
For ease of starting:
You may want to consider our TRC EZ START HIGH PERFORMANCE CDI
Part No. TRC-9745 (NOT FOR USE ON ZS190s)
One more thing:
At times it helps to just crack the throttle a
tiny bit to let air in.
