Nibbi helped perfect the simple design of the PE30. Starting with looks, they come hard anodized black. This helps with corrosion resistance, wear resistance, insulation, heat resistance and hardness/strength of the carburetor. The air passage starts out anodized then transitions into a smooth polished finished for optimal power and smooth consistent power. Another huge benefit is the splash guard, which keeps the engine operating smooth under bumpy riding.
Key Features:
- Polished round slide for improved throttle response, overall smoothness, and stability in use
- Air passage is mostly polished smooth for more power and consistency
- Lightweight anodized hardware
- Huge splash guard for smooth operation
- Anodized, which greatly improves the corrosion resistance, wear resistance, insulation, heat resistance and hardness or strength of the carburetor
- Works with TBparts intakes with TBW432 boot and Stock China intakes with TRC-0599 boot
Specifications:- OD at spigot end - 33mm
- OD at filter end - 48mm
Includes:
- Main jets #122, #125, #130 (Stock is #128)
- Pilot jet #35 (Stock is #40)
Recommended:
- Air filter - TBW0491
- Main jet kit - TBW0327
- Pilot jet kit - TBW0363
